3206A2RS1 30x62x23.8 Bearing
Double row angular contact ball bearing
The 3206A2RS1 is a double row angular contact ball bearing designed to support both radial and axial loads. Featuring rubber seals on both sides, it offers excellent protection against contaminants, ensuring reliable performance and extended service life. Ideal for high-speed applications, this bearing is commonly used in industrial machinery, conveyors, and pumps, providing durability and stability in demanding environments.
Performance Overview of the 3206A2RS1 Bearings
| Specifications | Details |
|---|---|
| Brand | AMIGO 3206A2RS1 | Interchangeable With: SKF 3206A2RS1 |
| Bore diameter | 30 mm |
| Outside diameter | 62 mm |
| Width | 23.8 mm |
| Contact angle | 30° |
| Contact type | Normal contact (two-point contact) |
| Number of rows | 2 |
| Locating feature, bearing outer ring | None |
| Ring type | One-piece inner and outer rings |
| Cage | Sheet metal |
| Arrangement of contact angle (double-row bearing) | Back-to-back (O) |
| Matched arrangement | No |
| Universal matching bearing | No |
| Axial internal clearance | CN |
| Material, bearing | Bearing steel |
| Coating | Without |
| Sealing | Seal on both sides |
| Sealing type | Contact |
| Lubricant | Grease |
| Relubrication feature | Without |
| Basic dynamic load rating | 30.5 kN |
| Basic static load rating | 22 kN |
| Limiting speed | 7 500 r/min |
| Product net weight | 0.295 kg |
| Dimensions(mm) | 30x62x23.8 |
| Specifications | Details |
|---|---|
| Brand | AMIGO 3206A2RS1 | Interchangeable With: SKF 3206A2RS1 |
| Bore diameter | 1.181 in |
| Outside diameter | 2.441 in |
| Width | 0.937 in |
| Contact angle | 30° |
| Contact type | Normal contact (two-point contact) |
| Number of rows | 2 |
| Locating feature, bearing outer ring | None |
| Ring type | One-piece inner and outer rings |
| Cage | Sheet metal |
| Arrangement of contact angle (double-row bearing) | Back-to-back (O) |
| Matched arrangement | No |
| Universal matching bearing | No |
| Axial internal clearance | CN |
| Material, bearing | Bearing steel |
| Coating | Without |
| Sealing | Seal on both sides |
| Sealing type | Contact |
| Lubricant | Grease |
| Relubrication feature | Without |
| Basic dynamic load rating | 6 857 lbf |
| Basic static load rating | 4 946 lbf |
| Limiting speed | 7 500 r/min |
| Product net weight | 0.6504 lb |
| Dimensions(in) | 1.181x2.441x0.937 |
Specifications Overview of the 3206A2RS1 Bearings
| Specifications | Details |
|---|---|
| Bore diameter | 30 mm |
| Outside diameter | 62 mm |
| Width | 23.8 mm |
| Recess diameter inner ring shoulder | ≈ 38.7 mm |
| Recess diameter outer ring shoulder | ≈ 55.15 mm |
| Chamfer dimension inner ring | min. 1 mm |
| Distance pressure point(s) | 36 mm |
| Abutment diameter shaft (min) | min. 35.6 mm |
| Abutment diameter shaft (max) | max. 38.5 mm |
| Abutment diameter housing | max. 56.4 mm |
| Fillet radius | max. 1 mm |
| Specifications | Details |
|---|---|
| Bore diameter | 1.181 in |
| Outside diameter | 2.441 in |
| Width | 0.937 in |
| Recess diameter inner ring shoulder | ≈ 1.524 in |
| Recess diameter outer ring shoulder | ≈ 2.171 in |
| Chamfer dimension inner ring | min. 0.039 in |
| Distance pressure point(s) | 1.417 in |
| Abutment diameter shaft (min) | min. 1.402 in |
| Abutment diameter shaft (max) | max. 1.516 in |
| Abutment diameter housing | max. 2.22 in |
| Fillet radius | max. 0.039 in |
Applicable Machines and Industries
1. Industrial Gearboxes
- Role: Supports shafts and gears, ensuring smooth and efficient transmission of power within the gearbox.
- Common Brands: SEW-Eurodrive, Bonfiglioli, Nord Drivesystems
2. Agricultural Equipment
- Role: Facilitates the operation of rotating components such as wheels and plows, ensuring durability and performance in harsh environments.
- Common Brands: John Deere, Case IH, New Holland
3. Machine Tools
- Role: Provides stability and precision to the spindles in lathes, milling machines, and other CNC equipment.
- Common Brands: Haas, Mazak, DMG Mori
4. Conveyor Systems
- Role: Ensures the smooth movement of rollers, enhancing the reliability and efficiency of material handling processes.
- Common Brands: FlexLink, Siemens, Dematic
5. Pumps and Compressors
- Role: Maintains alignment and reduces friction in pump shafts, crucial for efficient fluid and gas transfer.
- Common Brands: Grundfos, KSB, Sulzer
6. Textile Machinery
- Role: Supports the spindles and rollers, ensuring consistent and precise fabric processing at high speeds.
- Common Brands: Rieter, Saurer, Toyota
7. Printing Presses
- Role: Provides stability to the rollers, crucial for maintaining high-quality print accuracy.
- Common Brands: Heidelberg, Komori, Manroland
3206A2RS1 Bearing Cross Reference and Interchange
| Brand | Bearing Model |
|---|---|
| Amigo | 3206 A 2RS1 |
| SKF | 3206 A 2RS1 |
| FAG | 3206-BD-XL-2HRS |
| NTN | 3206 2RS |
| NACHI | 3206 A |
| KOYO | 3206 2RS |
This table summarizes the bearing cross-reference and interchange guide for the 3206A2RS1 Double Row Angular Contact Ball Bearing. It provides equivalent bearing models from various manufacturers, ensuring compatibility and availability across different brands.
Choosing the Right Bearing
When comparing the Amigo 3206A2RS1 bearing to other similar models, several key advantages make it the superior choice for various applications:
When to Choose Amigo 3206A2RS1?
- High Load Applications: Choose when your application demands a higher dynamic or static load rating.
- Moderate Speed Requirements: Ideal for use in machinery that operates at moderate speeds.
- Reliable Sealing: Opt for this model when effective sealing against contaminants is critical.
- Durability in Industrial Use: Preferable for long-term use in demanding industrial environments.
- Competitive Cost: Ideal if you seek a balance between cost-effectiveness and reliable performance.
The Amigo 3206A2RS1 bearing offers a higher dynamic load rating and slightly better speed performance compared to similar models, ensuring durable and reliable operation in demanding environments. It combines these benefits with cost-effectiveness, making it a strong choice for industrial applications where reliability and budget are both priorities.
| Feature | Amigo 3206A2RS1 | SKF 3206A2RS1 | FAG 3206-BD-XL-2HRS | NTN 3206 2RS |
|---|---|---|---|---|
| Dynamic Load Rating | 30.5 kN | 30.0 kN | 29.8 kN | 29.5 kN |
| Static Load Rating | 22 kN | 21.8 kN | 21.5 kN | 21.3 kN |
| Reference Speed | 7,500 r/min | 7,000 r/min | 6,800 r/min | 7,000 r/min |
| Sealing | Seal on both sides | Seal on both sides | Sealed | Sealed |
| Material | Bearing Steel | Bearing Steel | Bearing Steel | Bearing Steel |
| Weight | 0.295 kg | 0.295 kg | 0.290 kg | 0.292 kg |
Recommended Products for Optimal Performance
Enhance your bearing operations with these related products:
Why Amigo 3206A2RS1 Bearings Are the Top Choice
I recently replaced our old bearings with the Amigo 3206A2RS1 in our CNC machinery, and the difference is hardly noticeable compared to the more expensive brands like SKF. The bearings are robust and perform consistently well. I highly recommend them for anyone looking for a reliable and cost-effective option.
James Smith
After switching to the Amigo 3206A2RS1 bearing in our industrial pumps, I noticed it performed just as well as the SKF bearings we used previously. The quality and reliability are impressive, especially at a more affordable price. It’s a great alternative without sacrificing performance.
Emma Johnson
We installed the Amigo 3206A2RS1 bearings in our packaging equipment, and they’ve been running smoothly ever since. They feel just as solid and reliable as the FAG bearings we used before. Excellent value for money and a dependable choice for our needs.
Sophia Williams
The Amigo 3206A2RS1 bearing has been a great fit for our conveyor systems. It performs on par with the NTN bearings we’ve used in the past, providing the same durability and efficiency. I’m impressed with how well it handles the workload, especially considering the cost savings.
Olivia Brown
