3206 A-2RS1TN9MT33 30x62x23.8 Bearing
Double row angular contact ball bearing
The 3206 A-2RS1TN9/MT33 Double Row Angular Contact Ball Bearing is a robust and versatile bearing solution designed to handle both radial and axial loads, making it ideal for a wide range of industrial applications. This bearing is particularly well-suited for scenarios where space is limited and both types of loads must be accommodated, as its double-row design effectively manages the stresses that typically require two single-row bearings.
Performance Overview of the 3206 A-2RS1TN9MT33 Bearings
| Category | Specification |
|---|---|
| Brand | AMIGO 3206 A-2RS1TN9MT33| Interchangeable With: SKF 3206 A-2RS1TN9MT33 |
| Bore Diameter | 30 mm |
| Outside Diameter | 62 mm |
| Width | 23.8 mm |
| Contact Type | Normal contact (two-point contact) |
| Number of Rows | 2 |
| Locating Feature, Bearing Outer Ring | None |
| Ring Type | One-piece inner and outer rings |
| Cage | Non-metallic |
| Arrangement of Contact Angle (Double-row bearing) | Back-to-back (O) |
| Matched Arrangement | No |
| Universal Matching Bearing | No |
| Axial Internal Clearance | CN |
| Material, Bearing | Bearing Steel |
| Coating | Without |
| Sealing | Seal on both sides |
| Sealing Type | Contact |
| Lubricant | Grease |
| Relubrication Feature | Without |
| Basic Dynamic Load Rating | 30.5 kN |
| Basic Static Load Rating | 22 kN |
| Limiting Speed | 7 500 r/min |
| Product Net Weight | 0.283 kg |
| Dimensions(mm) | 30x62x23.8 |
| Category | Specification |
|---|---|
| Brand | AMIGO 3206 A-2RS1TN9MT33| Interchangeable With: SKF 3206 A-2RS1TN9MT33 |
| Bore Diameter | 1.181 in |
| Outside Diameter | 2.441 in |
| Width | 0.937 in |
| Contact Type | Normal contact (two-point contact) |
| Number of Rows | 2 |
| Locating Feature, Bearing Outer Ring | None |
| Ring Type | One-piece inner and outer rings |
| Cage | Non-metallic |
| Arrangement of Contact Angle (Double-row bearing) | Back-to-back (O) |
| Matched Arrangement | No |
| Universal Matching Bearing | No |
| Axial Internal Clearance | CN |
| Material, Bearing | Bearing Steel |
| Coating | Without |
| Sealing | Seal on both sides |
| Sealing Type | Contact |
| Lubricant | Grease |
| Relubrication Feature | Without |
| Basic Dynamic Load Rating | 6 857 lbf |
| Basic Static Load Rating | 4 946 lbf |
| Limiting Speed | 7 500 r/min |
| Product Net Weight | 0.6239 lb |
| Dimensions(mm) | 30x62x23.8 |
Specifications Overview of the 3206 A-2RS1TN9MT33 Bearings
| Dimensions | Value |
|---|---|
| Bore Diameter | 30 mm |
| Outside Diameter | 62 mm |
| Width | 23.8 mm |
| Chamfer Dimension Inner Ring (r1,2) | min. 1 mm |
| Distance Pressure Point(s) (a) | 36 mm |
| Dimensions | Value |
|---|---|
| Bore Diameter | 1.181 in |
| Outside Diameter | 2.441 in |
| Width | 0.937 in |
| Chamfer Dimension Inner Ring (r1,2) | min. 0.039 in |
| Distance Pressure Point(s) (a) | 1.417 in |
Applicable Machines and Industries
The 3206 A-2RS1TN9/MT33 Double Row Angular Contact Ball Bearing is commonly used in various types of machinery where both radial and axial loads need to be supported simultaneously. Here’s a list of machines where this bearing is typically applied, the role it plays in these machines, and some of the common brands associated with them:
1. Industrial Gearboxes
Role: Supports the shafts and helps in smooth transmission of power, handling both radial and axial loads effectively.
Common Brands:Siemens、SEW-EURODRIVE、Bonfiglioli
2. Pumps (Centrifugal, Hydraulic, etc.)
Role: Provides stable support for the pump shafts, ensuring the efficient operation of the pump under various load conditions.
Common Brands:Grundfos、KSB、Wilo
3. Electric Motors
Role: Supports the motor shaft and handles both radial and axial forces, which helps in maintaining motor efficiency and longevity.
Common Brands:ABB、Siemens、Toshiba
4. Conveyor Systems
Role: Supports the conveyor rollers, ensuring smooth and continuous operation under heavy load conditions.
Common Brands:FlexLink、Dorner、Rexnord
5. Agricultural Machinery (Tractors, Harvesters)
Role: Facilitates the movement of rotating parts and supports loads in agricultural equipment, ensuring durability and operational efficiency.
Common Brands:John Deere、Kubota、New Holland
3206 A-2RS1TN9MT33 Bearing Cross Reference and Interchange
| Brand | Bearing Model |
|---|---|
| SKF | 3206 A-2RS1TN9MT33 |
| FAG | 3206 A-2RS1 |
| Amigo | 3206 A-2RS1TN9MT33 |
| KOYO | 3206 |
Above is a table showing cross reference and exchange information for 3206 A-2RS1TN9MT33 double row angular contact ball bearings with seals or dust shields.
Choosing the Right Bearing
Choosing the Amigo 3206 A-2RS1TN9MT33 bearing is a smart decision for those looking for a reliable, high-performance bearing that offers excellent value for money.
When to Choose 3206 A-2RS1TN9MT33 Bearings:
The 3206 A-2RS1TN9MT33 bearing is a double-row angular contact ball bearing designed for applications where both radial and axial loads are present, and where high rigidity and high speed are required. These bearings are commonly used in machinery such as pumps, gearboxes, compressors, and electric motors.
Situations where 3206 A-2RS1TN9MT33 bearings are ideal:
- Limited Space: The double-row design allows for a compact bearing arrangement, which is beneficial when space is limited.
- High Load Capacity: The 3206 A-2RS1TN9MT33 can handle high radial and axial loads in both directions, making it ideal for heavy-duty applications.
- Longer Bearing Life: The sealed design ensures that the bearing is protected from contaminants and retains lubrication, which prolongs its service life.
Advantages of Amigo 3206 A-2RS1TN9MT33 Over Other Models:
- Cost-Effective: Amigo offers a more economical option without compromising on quality, providing similar performance to higher-priced brands like SKF and FAG.
- High-Quality Materials: Made from high-grade bearing steel, Amigo bearings ensure durability and reliability in demanding applications.
- Advanced Sealing: The sealed construction helps prevent the ingress of contaminants, reducing maintenance needs and extending the life of the bearing.
| Feature | Amigo 3206 A-2RS1TN9MT33 | SKF 3206 A-2RS1TN9MT33 | FAG 3206 A-2RS1 | KOYO 3206 |
|---|---|---|---|---|
| Dynamic Load Rating | 30.5 kN | 30.5 kN | 30.5 kN | 30.5 kN |
| Static Load Rating | 22 kN | 22 kN | 22 kN | 22 kN |
| Fatigue Load Limit | 0.93 kN | 0.93 kN | 0.93 kN | 0.93 kN |
| Sealing Type | Sealed on Both Sides | Sealed on Both Sides | Sealed on Both Sides | Sealed on Both Sides |
| Material | Bearing Steel | Bearing Steel | Bearing Steel | Bearing Steel |
| Price | More Economical | Higher | High | Moderate |
| Availability | Widely Available | Widely Available | Widely Available | Widely Available |
